Moticams

MOTICAM 2000 SERIES DIGITAL CAMERAS

The Moticam 2000, 2300 and 2500 models are compact and lightweight cameras that attach to virtually any microscope through the eyepiece, eyetube or trinocular port. Easy Plug & Play USB2.0 Hi-Speed connection ensures crisp and clear real-time preview images displayed on the computer monitor, turning any microscope into a Digital Microscope. Use these cameras with your own software through a TWAIN interface or use the included Motic Images Plus 2.0 application software on both Windows and Macintosh systems. The complete set of accessories gives the hi-resolution cameras the ability to be used in many different applications from Macro to Micro.

These cameras offer the following features and include all items listed:

· C-mount camera with 1/2” CMOS chip and TWAIN driver

· 2000—2.0 Mega pixels (1600 X 1200) with USB 2.0 PC output with 16mm macro lens

· 2300—3.0 Mega pixels (2048 X 1536) with USB 2.0 PC output with 16mm macro lens

· 2500—5.0 Mega pixels (2592 X 1944) with USB 2.0 PC output with 16mm macro lens

· Four different eyepiece adapters (to fit outside diameters of eyepieces 28mm, 30mm, 34mm, and 35mm ).

· Certified Calibration Slide

· Motic Images Plus 2.0 Software (PC or Mac)

· Maximum Frame Rate - 10fps @max res, 40fps with binning

· Minimum Illumination - 3 lux

· Camera Power Supply - 5V self-power through USB connection

· Minimum System Requirements - P3, 1GB HD Space, 256MB RAM, 32MB Display Memory, Windows XP or 2000, USB2.0

- G4, 1GB HD Space, 256MB RAM, OSX, USB connection

Moticam 2000 $678.03

Moticam 2300 $949.05IN STOCK

Moticam 2500 $1281.55 IN STOCK

Upgrade to Images Advanced 3.2 software $449

Note: These models are now currently compatible

with Windows Vista and 64 bit computers.

MOTICAM 480 DIGITAL CAMERA
View images on your computer and TV monitor at the same time!
480 TV Lines of Resolution, and full-screen computer imaging.

Moticam 480 has all of the features of our Moticam 350, with the added benefit of both Digital and Analog outputs. These separate outputs allow you to connect the camera to a computer or a TV monitor, or better yet, both at the same time. The CCD camera provides 480 TV lines of resolution, giving you crisp and clear representations of microscopic images. You can use the analog output with a TV monitor to show students live action movement on a full-screen, or simply to introduce a topic.

Price $711.55

Moticam 483 Gooseneck Mounted version $799

DC Imaging, LLC

Moticam 480 standard package includes:

· Moticam 480 CCD camera with C-mount ring.

· 12mm CCTV lens.

· Four different eyepiece adapters (to fit outside diams of eyepieces 28mm, 30mm, 34mm, and 35mm ).

· Connecting cables: USB (3m), RCA and S-Video (2m).

· Two calibration slides.

· Macro Tube viewing tube

· 12V linear switching power supply.

· Motic Images Plus 2.0 Software and Quick start Guide

MOTICAM 1000 DIGITAL CAMERA

Maximum pixels for a Minimum Price

The Moticam 1000 features 1.3 Megapixel resolution using a

Hi-Speed USB2.0 Plug & Play connection. No extra power supply is needed. A newly designed capture interface offers easy operation without taking away the possibility for individual adjustments. This interface allows the viewer to preview live images up to 1240 X 1024 and to capture the best possible image representing true color and background correction.

Price $387.03

Moticam 1000 is not compatible with MS Vista.
